Rotax 发动机额外加装发电机功率600W
1121
2

Rotax 912 IS 发动机带有发电机A和B,功率为:220W和420W

The internal generator has two isolated coils integrated (individual generators).During the starting operation, the EMS system is powered by the

battery. With sufficient speed generator B takes over this function. After the EMS system check, generator A takes over the supply of the EMS

system (engine), if the switching threshold is exceeded. Generator B is then used to supply the aircraft instruments and for charging the battery.

While the engine is running, generator B can be used for the board instrumentation.

- Generator A 14.2 V/16 A (220 W nominal capacity at 20°C/68 °F)

- Generator B 14.2 V/30 A (420 W nominal capacity at 20°C/68 °F)


对于需要用到大功率设备,Rotax也为客户提供额外发电机。其功率为550W。

 external alternator

1 External alternator

2 Positive terminal

3 Control wiring

Technical data

Output Max. 550 W/DC at 6000 r.p.m.

(complies ~ 4800 r.p.m. crankshaft speed)

Output voltage 14.2 V – 14.8 V

Ambient temperature Min. -30 °C (-22 °F)

Max. +90 °C (194 °F)

Connections

Power supply wires

Power supply wires to external alternator (1) have to be installed depending on the mounting position and according to the regulations of the aircraft manufacturer.

Positive terminal

M6 screw connection suitable for cable terminal according to DIN 46225 (tightening torque 4 Nm (35 in.lb)).

Grounding

Via engine block.

Control wiring

Via supplied standard plug (Sumitomo 6111-2568) and6.3 x 0.8 Faston connectors (female).



3
